DECHUANG Deepkaler 140-4-4300 Front Mount Telescopic Hydraulic Cylinder for Dump Truck

140-4-4300

BRAND DECHUANG

MODEL 140-4-4300

VEHICLE TYPE Heavy Duty Dump Truck / Tipper Truck

PRODUCT NAME Front Mount Telescopic Hydraulic Cylinder

HYDRAULIC CYLINDER BRAND Deepkaler

PRODUCT TYPE Multi-Stage Telescopic Hydraulic Cylinder

INQUIRY NOW WHATSAPP

Configuration, export documentation and worldwide delivery support are available.

Verified sourcingExport documentsGlobal delivery

PRODUCT DETAILS

Model: 140-4-4300
Product: Front Mount Telescopic Hydraulic Cylinder
Hydraulic Cylinder Brand: Deepkaler
Cylinder Diameter: 140 mm
Number of Stages: 4 Stages
Stroke: 4300 mm
Lifting Capacity: 40–50 Tons
Application: Heavy Duty Dump Truck / Tipper Truck
Installation Type: Front Mount / Front End
System: Dump Body Hydraulic Lifting System
Function: Dump Body Lifting and Tipping
Condition: New
Supplier: DECHUANG

DECHUANG supplies the Deepkaler 140-4-4300 front mount telescopic hydraulic cylinder for compatible heavy-duty dump trucks and tipper trucks. The cylinder is designed as the main lifting actuator in a front-end hydraulic tipping system and is suitable for dump body lifting, unloading, repair and replacement applications.

The 140-4-4300 configuration features a 140 mm cylinder diameter, 4-stage telescopic structure and 4300 mm stroke. The listed lifting capacity is 40–50 tons, making this model suitable for demanding heavy-duty dump truck hydraulic lifting applications.

Product Specifications

Product Name	Front Mount Telescopic Hydraulic Cylinder
Model	140-4-4300
Supplier Brand	DECHUANG
Hydraulic Cylinder Brand	Deepkaler
Product Type	Multi-Stage Telescopic Hydraulic Cylinder
Cylinder Diameter	140 mm
Number of Stages	4 Stages
Stroke	4300 mm
Listed Lifting Capacity	40–50 Tons
Installation Type	Front Mount / Front End
Vehicle Type	Heavy Duty Dump Truck / Tipper Truck
System	Dump Body Hydraulic Lifting System
Main Function	Dump Body Lifting and Tipping
Condition	New
Product Category	Chassis Parts / Hydraulic System Parts

Applications

DECHUANG Deepkaler 140-4-4300 telescopic hydraulic cylinder is suitable for compatible heavy-duty dump trucks and tipper trucks using front-end hydraulic lifting systems.

During unloading, hydraulic oil enters the cylinder and extends the telescopic stages sequentially. The cylinder raises the front section of the dump body and creates the tipping angle required for material discharge.

The 4-stage telescopic design provides a 4300 mm stroke while maintaining a relatively compact retracted configuration. This makes the cylinder suitable for dump trucks requiring substantial body lifting travel with limited chassis installation space.

The listed lifting capacity of 40–50 tons makes the 140-4-4300 suitable for heavy-duty dump body applications. Actual system performance also depends on the vehicle configuration, mounting geometry, hydraulic pressure and complete tipping system setup.

Typical applications include dump trucks operating in construction, mining, quarrying, infrastructure development, earthmoving, aggregate transportation and bulk material handling.

The 140-4-4300 hydraulic cylinder can also be used as a replacement component when the original cylinder develops hydraulic oil leakage, damaged seals, abnormal extension, insufficient lifting performance, deformation or other mechanical damage.

Hydraulic cylinder compatibility should not be determined only according to truck brand or cargo body size. The cylinder model, mounting arrangement, original installation dimensions and hydraulic system configuration should also be checked.

Before ordering, please confirm the complete model 140-4-4300. Customers can also provide the original cylinder nameplate, truck model, dump body dimensions and clear installation photos for additional matching.

DECHUANG can also supply related dump truck hydraulic components including hydraulic pumps, PTO units, proportional control valves, limit valves, hydraulic oil tanks, hoses, brackets, seal kits and complete hydraulic lifting system solutions.

Why Choose DECHUANG

DECHUANG supplies Deepkaler telescopic hydraulic cylinders and heavy-duty dump truck hydraulic system components for international commercial vehicle markets.

Our hydraulic product range includes front-end telescopic cylinders, hydraulic pumps, PTO units, proportional control valves, limit valves, oil tanks, hoses, brackets and complete hydraulic lifting system kits.

DECHUANG supports product matching according to hydraulic cylinder model, original nameplate, truck configuration, dump body dimensions and installation information.

We support individual replacement orders, mixed spare parts purchasing and bulk B2B supply for truck parts distributors, hydraulic repair workshops, dump truck fleets, mining companies and construction projects.

Customers searching for Deepkaler 140-4-4300, 140 mm telescopic hydraulic cylinder, 4-stage dump truck cylinder, 4300 mm stroke cylinder or 40–50 ton tipper hoist cylinder can contact DECHUANG for product matching and quotation.
